Acoustic Floor Mat 29
AFM 29 is a homogeneous impact noise insulation made of polyurethane with a particularly high load capacity of 50 kN/m² and an effectiveness of 29 dB in conjunction with a lower installation height of only 11 mm. These properties make AFM 29 particularly suitable for highly stressed areas such as supermarkets, but also for renovations and for use beneath dry screeds.
Product properties AFM 29
- Impact sound reduction ∆Lw: 29 dB
- Dynamic stiffness st': ≤ 10 MN/m³
- Load range: 5,000 kg/m²
- Thickness: 11 mm
- Standard delivery form: 1500x750 mm
- Compressibility c: ≤ 1 mm
- Flammability: Class E
- Thermal conductivity λ: 0.06 W/mK
1
/ 4
Advantages and benefits
- Consistent effectiveness over the entire load range
- Low installation height - thus particularly suitable for renovation projects
- Quick installation - no need for bonding to the subsurface
- Easy handling
- Outstanding durability over decades
Documents available for download
6 documents available
Overview of Acoustic Floor Mat portfolio
